PRODUCT FEATURES & BENEFITS
Conserves Water & Enhances Landscapes
- Evapotranspiration (ET) Technology: Identi es the absolute minimum amount of water necessary to maintain healthy lawn or garden.
- Smart-Cycle strengthens root structures and eliminates runoff with a cycle-and-soak method ideal for location’s soil type.
- Automatically calculates and adjusts watering schedules.
- Hyper-local based weather data. Automatic rain and freeze delay is built-in.
Simple Installation and Easy to Use
- Painless “plug & play” installation takes minutes.
- Compatible with all industry standard 24V AC solenoids.
- No subscription fees. Download our free app for your
- Apple iOS or Android device.
- Monitor and control sprinkler system remotely via WIFI using your smartphone or through our web interface.
- Tracks water usage with personalized reports.
- Email & Push noti cation alerts for zone activity, weather updates, and seasonal adjustments to watering times
- Reduce water use by as much as 30%. ROI can be just a few months, and faster with rebates.
MECHANICAL SPECIFICATIONS
Controller Specs
- Dimensions: 2.165” x 7.25” x 7.25”
- Weight: 3 lbs
- Indoor Use Only (Outdoor Installation With WeathervProof Enclosure)
- Temperature Range: -31°F - 140°F
- Electrical Requirements: US Standard
- Power Supply: External Transformer (6’ ft cord)
- Transformer Power Input: 120v - 38 watts
- Transformer Power Output: 24v - 1.3 amps
- Designed For Industry Standard 24v AC Solenoids
- Two solenoids may be paired to one zone
- Sensor Port Functionality
- Support for wired open/closed contact sensors included rain or soil moisture
- Master Valve/Pump Control
- Package Contains: Smart Sprinkler Controller (Front Panel + Wall Mount), AC Power Adapter, Wall Screws, Quick Install Guide
- Smart Sprinkler Controller
- Designed and Made in the USA
Controller Specs
EPA Watersense
FCC
UL
Software Requirements
Android (4.3 or later)
iOS (7.1 or greater
Wifi/Connectivity Requirements
Internet Connected 802.11b/g/n (2.4ghz) (WPS and WPA2 Enterprise are not supported)
In the event of a power outage or WiFi intermittency, the device’s memory retains the last saved schedule received from the Rachio cloud and maintains the schedule until an update can be downloaded.
Warranty
2 Year Limited
